Projecta 6/12/24V Automatic and Manual 12 Amp 2 Stage Battery Charger - HDBC20

Projecta 6/12/24V Automatic & Manual 12A 2 Stage Battery Charger – HDBC20

The HDBC20 is a powerful and versatile battery charger designed for mechanical workshops and auto electricians. It offers multi-voltage operation, automatic or manual charging, an engine start function, and a built-in 0–14 hour timer for reliable and flexible charging.

Features

• Multi-voltage: 6V, 12V, or 24V operation
• Automatic or manual charging modes
• Engine start function: 50A at 3.6V, 50A at 7.2V, 25A at 14.4V (5 cycles, 5 min on/5 min off)
• 0–14 hour timer with auto shut-off
• 5-year warranty

Specifications

• Part No: HDBC20
• Type: 2 Stage Automatic & Manual
• Input: 240V, 50Hz, 324W
• Output Current: 12A at 6V, 12A at 12V, 7.7A at 26V
• Charge Voltage: Cut-out: 7.1V (6V), 14.2V (12V), 28.4V (24V); Cut-in: 6.7V (6V), 13.4V (12V), 26.8V (24V); Start: 0.0V
• Engine Start: 5 cycles (5 min on, 5 min off)
• Approvals: Electrical Safety, EMC

LED Charge Indication

• Red light flashing: Overload
• Second red light on: Power on
• Second red light flashing: Reverse connection
• Amber light on: Charging
• Green light on: Fully charged

LED Screen: Displays voltage/current

Battery Charge Times

• Automotive: 6V/12V/24V, 450–1200CCA → 6–15 hrs
• Marine: 6V/12V/24V, 600–1400MCA → 8–18 hrs
